PIR Panel

Polyisocyanurate (PIR) is a type of fire-resistant panel. In the event of fire, PIR Panel simply chars. Properly installed PIR panels can significantly reduce serious risks of property damage and loss of business due to fire.

PIR Panel is a rigid polyurethane foam made, as all rigid polyurethanes, by mixing two chemical streams (isocyanate and polyol) with appropriate catalysts and a blowing agent.

PIR Panel is available for insulated wall and ceiling panels (1,170 mm and 1,200 mm wide) and insulated external roofing panels (1,000 mm to 1.200 mm wide). Insulated wall and ceiling PIR panels are available in thicknesses of 50, 75, 100, 150, 200 mm and in three different skins: Diamond, Rib and Plain with sheet metal thickness of 0.5 mm and 0.6 mm.

Panels are supplied with an adhered plastic film to protect the metal skins during transport and construction.

PIR Panel is suitable for all insulated panel applications, including cold stores. The PIR Panels are now manufactured in Indonesia. Its fire risk reduction qualities have been proven to meet specifications in Australia, Europe and USA.
Core


Width (cover mm)
Thickness (mm)
Length
Exterior Facing Skin
Internal Facing Skin
Standard Colors
Joint System
Finishes
Type of Skin
PIR
(Fire-Resistant Polyisocyanurate)

1,170
50, 75, 100, 150
Up to 12 meters
0.5mm, 0.6mm G300 CRP Steel
0.5mm, 0.6mm G300 CRP Steel
Off White
Slip Joint
Plain, Ribbed, Diamond
Anti Bacterial (AB)
Food Grade (FG)
Xterior Roof and Wall (XRW)

Features and Advantages

  • Fire resistant (with burning classification PIR B2 DIN 4102)
  • Meets safety requirements
  • Energy saving
  • Longer lifetime
  • Resistant to termites and rodents
  • Customized design
  • Easy to install saving cost of installation time
  • High performance on insulated panel
